Creating a Zero-Knowledge Onchain Verifier: A Beginner's Guide

Introduction

Zero-knowledge proofs (ZKPs) are cryptographic methods that allow one party (the prover) to prove to another party (the verifier) that a statement is true without revealing any additional information beyond the validity of the statement itself. When implemented on a blockchain, these verifiers enable powerful privacy-preserving applications.

This tutorial will guide you through creating a simple ZK onchain verifier using Circom and Solidity. We'll build a basic system where a user can prove they know a secret number without revealing it.

Prerequisites

Before we begin, make sure you have:

• Node.js and npm installed

• Basic understanding of Solidity

• Familiarity with basic cryptography concepts

• A code editor (VS Code recommended)

Setting Up the Development Environment

1. First, let's install the necessary tools:

npm install -g circom
npm install -g snarkjs

1. Create a new project directory and initialize it:

mkdir zk-verifier-tutorial
cd zk-verifier-tutorial
npm init -y

Understanding the Components

Our ZK system will consist of three main parts:

1. A Circom circuit (the proving system)

2. A Solidity verifier contract

3. A frontend application to interact with the system

Step 1: Creating the Circom Circuit

Let's create a simple circuit that proves knowledge of a secret number. Create a file named circuit.circom:

pragma circom 2.0.0;

template SecretNumber() {
    // Private input: the secret number
    signal private input secret;

    // Public input: the hash of the secret number
    signal public input hash;

    // Output: whether the proof is valid
    signal output out;

    // Component to compute hash
    component hash = Poseidon(1);

    // Connect the secret to the hash component
    hash.inputs[0] <== secret;

    // Verify that the provided hash matches the computed hash
    hash.out === hash;

    // Set output to 1 if verification passes
    out <== 1;
}

component main = SecretNumber();

Step 2: Compiling the Circuit

1. Create a build directory:

mkdir build

1. Compile the circuit:

circom circuit.circom --r1cs --wasm --sym -o build

1. Generate the proving and verification keys:

snarkjs groth16 setup build/circuit.r1cs pot12_final.ptau build/circuit_final.zkey

Step 3: Creating the Verifier Contract

Now, let's create a Solidity contract that will verify the proofs on-chain. Create a file named Verifier.sol:

// SPDX-License-Identifier: MIT
pragma solidity ^0.8.0;

import "@openzeppelin/contracts/access/Ownable.sol";

contract SecretNumberVerifier is Ownable {
    // Event emitted when a valid proof is submitted
    event ProofVerified(address indexed prover, uint256 hash);

    // Mapping to store verified hashes
    mapping(uint256 => bool) public verifiedHashes;

    // Function to verify the proof
    function verifyProof(
        uint[2] memory a,
        uint[2][2] memory b,
        uint[2] memory c,
        uint[1] memory input
    ) public returns (bool) {
        // Verify the proof using the verifier contract
        bool isValid = verify(a, b, c, input);

        if (isValid) {
            verifiedHashes[input[0]] = true;
            emit ProofVerified(msg.sender, input[0]);
        }

        return isValid;
    }

    // Function to check if a hash has been verified
    function isHashVerified(uint256 hash) public view returns (bool) {
        return verifiedHashes[hash];
    }
}

Step 4: Testing the System

Let's create a simple test script to verify our implementation. Create a file named test.js:

const { expect } = require("chai");
const { ethers } = require("hardhat");
const snarkjs = require("snarkjs");

describe("SecretNumberVerifier", function () {
  let verifier;
  let secret = 42; // Our secret number

  beforeEach(async function () {
    const Verifier = await ethers.getContractFactory("SecretNumberVerifier");
    verifier = await Verifier.deploy();
    await verifier.deployed();
  });

  it("Should verify a valid proof", async function () {
    // Generate proof
    const { proof, publicSignals } = await snarkjs.groth16.fullProve(
      { secret: secret },
      "build/circuit.wasm",
      "build/circuit_final.zkey"
    );

    // Verify on-chain
    const result = await verifier.verifyProof(
      [proof.pi_a[0], proof.pi_a[1]],
      [
        [proof.pi_b[0][0], proof.pi_b[0][1]],
        [proof.pi_b[1][0], proof.pi_b[1][1]],
      ],
      [proof.pi_c[0], proof.pi_c[1]],
      [publicSignals[0]]
    );

    expect(result).to.be.true;
  });
});

Understanding How It Works

1. The Circuit:

   • Takes a private input (the secret number) that only the prover knows

   • Uses the Poseidon hash function, which is specifically designed for zero-knowledge proofs and is more efficient than traditional hash functions like SHA-256 in ZK contexts

   • Performs a cryptographic verification by comparing the computed hash of the secret number with a provided hash value

   • Outputs a binary signal (1) if the verification succeeds, indicating that the prover indeed knows a number that produces the claimed hash

   • The circuit's constraints ensure that the prover cannot cheat by providing false inputs

2. The Verifier Contract:

   • Acts as an on-chain verifier that receives and processes the zero-knowledge proof

   • Takes three main components as input:

     • The proof itself (containing the cryptographic evidence)

     • Public inputs (like the hash value that was claimed)

     • Verification key (pre-computed during the trusted setup)

   • Implements the Groth16 verification algorithm, which is a specific type of zk-SNARK that's particularly efficient for blockchain applications

   • Maintains a mapping of verified hashes to prevent replay attacks and enable future reference

   • Emits events that can be used by frontend applications to track successful verifications

   • Runs entirely on-chain, ensuring the verification process is trustless and decentralized

3. The Proof Generation Process:

   • The prover starts with their secret number and the circuit's constraints

   • Uses snarkjs to generate a cryptographic proof that demonstrates knowledge of the secret number

   • The proof generation process involves:

     • Creating a witness (a set of values that satisfy the circuit's constraints)

     • Running the circuit with the witness to generate the proof

     • Formatting the proof according to the Groth16 protocol

   • The generated proof is then sent to the verifier contract

   • The contract performs the verification without ever learning the actual secret number

   • This entire process ensures that the prover can demonstrate knowledge of the secret number while maintaining complete privacy

Security Considerations

1. Circuit Security:

   • Ensure your circuit is properly constrained

   • Use well-audited cryptographic primitives

   • Consider side-channel attacks

2. Contract Security:

   • Implement proper access controls

   • Consider gas optimization

   • Add circuit-specific checks

3. System Security:

   • Protect private keys

   • Implement proper frontend security

   • Consider replay attacks

Next Steps

1. Advanced Features:

   • Add support for multiple secrets

   • Implement more complex circuits

   • Add frontend integration

2. Optimization:

   • Optimize circuit size

   • Reduce gas costs

   • Improve proof generation time

3. Integration:

   • Connect to a frontend application

   • Implement a user interface

   • Add more complex business logic

Resources

• Circom Documentation

• SnarkJS Documentation

• Zero Knowledge Proofs: A Technical Deep-Dive

• OpenZeppelin Contracts

Conclusion

This tutorial has introduced you to the basics of creating a zero-knowledge onchain verifier. You've learned how to:

• Create a basic Circom circuit

• Generate and verify proofs

• Deploy a verifier contract

• Test the system

Remember that this is a simplified example. Real-world applications often require more complex circuits and additional security considerations. Always audit your code and consider professional review for production systems.
